Trajan Scientific PEEK Tubing, Orange 1/32" OD x 0.020" ID x 5' Length
Product overview
The Trajan Scientific PEEK Tubing in orange, measuring 1/32" outer diameter (OD) and 0.020" inner diameter (ID) over a 5-foot (1.5-meter) length, is engineered for high-performance liquid chromatography (HPLC) and other analytical applications. Constructed from high-quality PEEK (Polyether Ether Ketone), this tubing offers exceptional chemical resistance and mechanical strength, making it ideal for use in demanding laboratory environments.
Key Features:
- Brand: Trajan Scientific
- Material: PEEK (Polyether Ether Ketone)
- Outer Diameter: 1/32 inch (0.8 mm)
- Inner Diameter: 0.020 inch (0.508 mm)
- Length: 5 feet (1.5 meters)
- Color: Orange
- Maximum Pressure: 5,000 psi (345 bar)
- pH Range: 2 to 14
- Maximum Operating Temperature: 100°C
- Applications: Suitable for HPLC, LCMS, and automation systems
This tubing is designed to ensure reproducibility in chromatographic flow rates and results, thanks to its smooth internal surface and tight tolerances. Its bio-inert and bio-compatible nature makes it suitable for a wide range of analytical applications.
Frequently Asked Questions
1. What is the Trajan Scientific PEEK Tubing, Orange 1/32" OD x 0.020" ID x 5' Length used for?
It is engineered for high-performance liquid chromatography (HPLC) and other analytical applications. Constructed from high-quality PEEK (Polyether Ether Ketone), this tubing offers exceptional chemical resistance and mechanical strength, making it ideal for use in demanding laboratory environments.
2. Is the Trajan Scientific PEEK Tubing, Orange 1/32" OD x 0.020" ID x 5' Length suitable for HPLC, LCMS, and automation systems?
Yes. It is designed for HPLC, LCMS, and automation systems, and offers an outer diameter of 1/32 inch (0.8 mm) and an inner diameter of 0.020 inch (0.508 mm) to support this kind of work.
3. What outer diameter and inner diameter does the Trajan Scientific PEEK Tubing, Orange 1/32" OD x 0.020" ID x 5' Length have?
It has an outer diameter of 1/32 inch (0.8 mm), an inner diameter of 0.020 inch (0.508 mm) and a length of 5 feet (1.5 meters), and is supplied under manufacturer part number 1301020004-5F.
4. What is the Trajan Scientific PEEK Tubing, Orange 1/32" OD x 0.020" ID x 5' Length made from and what features does it include?
It is made from PEEK (Polyether Ether Ketone). It also offers orange and tube length 1.5 m.
5. How does the Trajan Scientific PEEK Tubing, Orange 1/32" OD x 0.020" ID x 5' Length compare with the SCAT Quick Coupling Set II, Includes 360179 Quick Couplings (f) & 360190 Quick Coupling (m)?
For tubing applications, the Trajan Scientific PEEK Tubing, Orange 1/32" OD x 0.020" ID x 5' Length is differentiated by material PEEK (Polyether Ether Ketone) and outer diameter 1/32 inch (0.8 mm). The SCAT Quick Coupling Set II, Includes 360179 Quick Couplings (f) & 360190 Quick Coupling (m) from SCAT is another named option in the same product category. Compare the required specifications, compatibility and workflow requirements before selection.
Product Specifications
- HS Code #39173200
- ColourOrange
- Ext. Ø0.8 mm
- Int. Ø0.51 mm
- Length1.5 m
- MaterialPEEK
- Max. temp. resistance100 °C
- Operating pressure207 bar
- Temperature resistance100 °C
- UNSPSC41105108
