Representative Image

Heidolph Shaker ROTAMAX 120, Orbital Rotary Shaking, 200–300 1/min, 220x220 mm Useful Area

Brand:Heidolph

Plug type

Specifications

Compare models
HS Code #
84798200
Depth
310 mm
Depth moving table
220 mm
Dimensions (WxDxH)
245 x 310 x 125 mm
Display
Analogue
Power supply frequency
50/60 Hz
Height
125 mm
IP code
IP 30
Max. loading capacity
2 kg
Max. permitted ambient temp.
31 °C
Max. relative humidity rate
80 %

SG $3,133.42

Inc. GST

Available soon

Product description

The Heidolph Shaker ROTAMAX 120 is a high-performance orbital shaker designed for smooth rotary shaking of samples in laboratory environments. With a shaking frequency of 200–300 1/min and a 220x220 mm platform, it is ideal for mixing vessels such as flasks, beakers, or culture dishes. The stable design and precise motion make it suitable for long-term shaking applications in biological and chemical labs.

Key Features:

  • Brand: Heidolph
  • Shaking Frequency: Adjustable from 200 to 300 1/min for steady mixing
  • Shaking Type: Orbital rotary motion for consistent agitation
  • Useful Area: 220 x 220 mm platform for various lab containers
  • Application: Ideal for cell cultures, suspension reactions, and reagent mixing
  • Packaging: Complete unit ready for operation

The ROTAMAX 120 offers controlled orbital motion, making it an essential tool for laboratories that demand accuracy, durability, and quiet operation during mixing procedures.

Accessories

Accessories for shakers and mixers

ProductDescriptionForMfr#Part#AvailabilityPrice
Attachment for 10 test tubes 10 or 60mm ?Reax Top, Reax Control549-01000-009.730 045SG $164.92
Adapter for 20 test tubes dia. 10 to 18mmReax 2549-21000-009.730 222SG $869.06
Frame for tension roller only. Supplied without tension rollerUnimax 2010, Promax 2020, Polymax 2040549-50000-009.839 811SG $457.69
Tension roller and frame complete. Order at least 2Unimax 2010, Promax 2020, Polymax 2040549-58000-009.839 812SG $194.56
Universal perforated platform 2000Unimax 2010, Promax 2020, Polymax 2040549-59000-009.839 813SG $466.96
Attachment with 2 tension rollersVibramax 100, Rotamax 120549-81000-009.839 844SG $320.57
Test tube stand for up to 6 Eppendorf vessels (1.5ml)Reax Top, Reax Control549-04000-006.229 903SG $157.50
V2A support rod with vessel holderReax Top, Reax Control549-20000-009.730 021SG $285.36
Attachment for up to 4 conical separating funnels, 50ml or 100mlUnimax 1010, Duomax 1030, Polymax 1040, Promax 1020549-78000-009.839 871SG $791.23
Set of holders for four 0.5I bottlesReax 20/4, Reax 20/8, Reax 20/12549-27000-009.839 809SG $244.60
Universal perforated platform 1000Unimax 1010, Duomax 1030, Polymax 1040, Promax 1020549-59200-009.839 814SG $366.89
Spare tension rollerVibramax 100, Rotamax 12011-008-007-087.078 546SG $161.21
Tension plate for caps allows for the use of common bottles with dia. 94mmReax 20/4, Reax 20/8, Reax 20/1211-001-001-817.055 418SG $46.32
Attachment with 2 tension rollersUnimax 1010, Duomax 1030, Polymax 1040, Promax 1020549-70000-009.839 869SG $670.79
Size 2 separatory funnel clamp for platform 2000 (2000 ml - max. 2 per platform)Unimax 2010, Promax 2020, Polymax 2040549-61000-009.839 827SG $550.34
Size 1 separatory funnel clamp for platform 2000 (250 ml - max. 4, 500/1000ml - max. 3 per platform)Unimax 2010, Promax 2020, Polymax 2040549-57000-009.839 823SG $439.16
Universal adapter (for flasks, bottles, test tube racks, etc.)Reax 2549-30000-009.730 223SG $1,206.30
Spare tension rollerUnimax 1010, Duomax 1030, Polymax 1040, Promax 1020549-71000-009.839 870SG $231.62
Set of holders for four 1I bottlesReax 20/4, Reax 20/8, Reax 20/12549-26000-009.839 808SG $190.86
Multi-storey attachment. Includes perforated platform 2000 and 4 supporting rodsUnimax 2010, Promax 2020, Polymax 2040549-62000-009.839 826SG $830.14
Tray 100 with universal boringsVibramax 100, Rotamax 120549-59100-006.229 800SG $261.27

Heating module for Incubator 1000, Suitable for Heidolph Shakers

ProductPlug typeType of auxiliary energyMfr#Part#AvailabilityPrice
EUMains connection549-90010-009.839 875SG $3,001.86
CHMains connection549-90010-024.703 300SG $3,001.86
UKMains connection549-90010-014.703 299SG $3,001.86

Compare similar models

Shaker, orbital rotary shaking ROTAMAX 120 shaking frequency 200-300 1/min useful area 220x220 mm

Manufacturer P/N

544-41200-00

Part Number

9.839 837

Manufacturer

Heidolph

Plug type

EU

Shaker ROTAMAX 120-UK 220 x 220 mm useable space with rubber mat -Standard-

Manufacturer P/N

544-41200-06

Part Number

9.839 799

Manufacturer

Heidolph

Plug type

UK

Shaker ROTAMAX 120-CH 220 x 220 mm useable space with rubber mat  -Standard-

Manufacturer P/N

544-41200-02

Part Number

9.839 798

Manufacturer

Heidolph

Plug type

CH

Frequently asked questions

It is a high-performance orbital shaker designed for smooth rotary shaking of samples in laboratory environments. With a shaking frequency of 200–300 1/min and a 220x220 mm platform, it is ideal for mixing vessels such as flasks, beakers, or culture dishes. The stable design and precise motion make it suitable for long-term shaking applications in biological and chemical labs.
